The AXIS 200+ Web Camera is the world’s first self-contained Web server and network camera, includes everything you need to capture live images and deliver them to any desktop over intranets, the Internet, or mixed network environments.
    Just install the camera directly to your Ethernet network, ISDN line, or phone line via a dedicated or wireless modem and you’ll be ready to view images via a standard Web browser in no time. It’s the easy way to enhance your remote monitoring systems and increase the value of your network.

Wide Range of Applications

Use the AXIS 200+ Web Camera for everything from surveillance to remote alarm verification. Keep watch over sensitive areas, entrance lobbies, parking lots, and supply rooms. Monitor manufacturing operations and construction sites. Remotely verify alarm signals. Automatically send a time or event-triggered live image via e-mail. The possibilities are endless.

Install in Minutes

True plug-and-play installation takes only minutes. No extra system resources, special software, or file server involvement are needed. You can also connect the server to the network via a modem for remote applications. The camera has the ability to initiate a file transfer over phone lines or Ethernet to remote hosts.

Use in Any Environment

Open Web server design allows easy integration into intranet-based groupware applications as well as into the Internet itself. You can also use it in mixed operating environments, such as Windows, Mac, UNIX and OS/2. Viewing clients require only a standard Web browser and TCP/IP access.

Fast, Quality Imaging

Compress and send two high-quality images (352 x 288) per second. Using push technology, send up to six images per second over direct network connections. Larger images (up to 702 x 576) can be captured, and 2x zoom capability is now available.

Replaceable Lens

The standard AXIS 200+ lens can be replaced with any CS mount or C mount (with C/CS ring) lens. It also supports auto-iris lenses for bright environments.

Technical Specifications

MODEL

AXIS 200+ Web Camera
0064-2
Self-contained Web server and network camera

All systems running TCP/IP and having an HTTP browser supporting HTML version 0.9 or higher and JPEG files (e.g., Netscape Navigator 1.22 and Microsoft Internet Explorer 1.0 and higher)

ARP, RARP, BOOTP, TCP, IP, HTTP, SMTP, ICMP, FTP, SNMP, and DNS.
Via Modem: PPP, Z-modem

Assign an IP address via ARP, RARP, or BOOTP. Attach to Ethernet or modem for a remote application. No need for any special software, works with standard Windows, UNIX, and OS/2.

Configuration and status via standard HTTP browser

Password protection

Extended CRON service allows periodic com-mand execution within the AXIS 200+. This enables programming of events and/or time triggered functions.

Command examples:
File Transfer Protocol (FTP) and Simple Mail
Transfer Protocol (SMTP) for image transfer from the AXIS 200+ to e-mail addresses.
Online/Offline commands establish/terminate PPP connections to the AXIS 200+.

Images in compressed JPEG color formats, selectable sizes:

Huge size: 704 x 576
Full size: 352 x 288
Half size: 172 x 144

Typical file sizes are 23 Kbytes and 10 Kbytes
Picture angle: 51 deg. horizontal, 39 deg. vertical

The image size is programmable using CGI parameters up to a maximum size of 704 x 576. It is possible to do a zoom-in of 352 x 288.
Server push for live updated pictures.
Parameters for rotation, quality, mirroring, color, etc. can be set.

A full size JPEG file updated in 0.7 second. Up to 6 frames/second transmitted using server push

Ethernet 10baseT, RJ45 (twisted pair)

CPU: 32-bit RISC processor (ETRAX)
FLASH PROM: 2 Mbyte
RAM: 2 MByte

Direct digital, 24-bit color
CCD: 1/3" Hi-resolution 768 x 582 pixels
Optical filter : Quartz low pass filter with IR cut filtering

Lens mount: CS mount (C mount with C/CS ring); supports auto-iris lenses
Standard 200+ lens — Focal length: 5.5mm
Aperture: Fixed F2.0
Thread: M12P 0.5mm
Focus 0.5mm to infinity

ILLUMINATION

5 to 5,000 lux with standard 200+ lens
2 to 200,000 lux with an F1.0 AutoIris lens.
